viii
TROOPER B85 specications summary
Specications are subject to change without notice.
Back panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
2 x USB 3.0/2.0 ports (blue)
4 x USB 2.0/1.1 ports
1 x DVI port
1 x D-Sub port
1 x LAN (RJ-45) port
8-channel audio output
Internal I/O
connectors
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports (black)
1 x USB 3.0/2.0 connectors support additional 2 USB 3.0/2.0 ports (19-pin;
beige)
4 x SATA 6.0Gb/s connectors (black)
2 x SATA 3.0Gb/s connectors (beige)
1 x COM header
1 x TPM header
1 x CPU fan connector (4-pin; beige) for both 4-pin (PWM mode) and 3-pin
(DC mode) CPU coolers control
2 x Chassis fan connectors (4-pin; black)
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x Chassis intrusion jumper
1 x Clear CMOS jumper
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS
2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3, My Favorites, Quick Note, Last Modied log, F12 PrintScreen, F3
Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
WfM 2.0, DMI 2.7, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
ASUS/TUF CPU-Z
Anti-virus software (OEM version)
Operating system
support
Windows
®
8.1
Windows
®
8
Windows
®
7
Form factor
ATX form factor: 12 in x 7.1 in (30.5 cm x 18 cm)
