ASUS H170 PRO GAMING
1-3
1.2.4 Layout contents
1.3 Central Processing Unit (CPU)
ThismotherboardcomeswithasurfacemountLGA1151socketdesignedforthe6th
GenerationIntel
®
Core™i7/Core™i5/Core™i3,Pentium
®
andCeleron
®
processors.
Connectors/Jumpers/Slots/LED Page
1. LEDlightconnector(3-pinLED_LIGHT)
1-22
2. ATXpowerconnectors(24-pinEATXPWR,8-pinEATX12V)
1-17
3. CPU,CPUoptional,extension,andchassisfanconnectors(4-pinCPU_FAN,
4-pinCPU_OPT,5-pinEXT_FAN,4-pinCHA_FAN1~3)
1-19
4. Intel
®
LGA1151CPUsocket 1-3
5. DDR4DIMMslots 1-7
6. USB3.0connectors(20-1pinUSB3_12,USB3_34) 1-16
7. ModelNameLEDs 1-24
8. Intel
®
H170SerialATA6.0Gb/sconnectors(7-pinSATA6G_1~6,
SATAEXPRESS)
1-20
9. M.2Socket3 1-18
10. StandbyPowerLED(SB_PWR) 1-24
11. Thermalsensorconnector(2-pinT_SENSOR) 1-16
12. Systempanelconnector(20-5pinPANEL) 1-21
13. CPUOverVoltagejumper(3-pinCPU_OV) 1-12
14. ClearRTCRAM(2-pinCLRTC) 1-11
15. USB2.0connectors(10-1pinUSB910,USB1112,USB1314) 1-15
16. ROGExtensionconnector(18-1pinROG_EXT) 1-23
17. TPMconnector(14-1pinTPM) 1-22
18. Serialportconnector(10-1pinCOM) 1-15
19. Frontpanelaudioconnector(10-1pinAAFP) 1-18
20. SupremeFXLED 1-25
H170 PRO GAMING CPU socket LGA1151
