vii
H170 PRO GAMING specifications summary
(continued on the next page)
Multi-GPU
Support
Supports AMD
®
2-Way / Quad-GPU CrossFireX™ Technology
Audio
SupremeFX 8-Channel High Definition Audio CODEC
- Supports Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 115dB SNR stereo playback output
Audio Features
- SupremeFX Shielding™ Technology
- Premium audio capacitors
- Headphone AMP
- Optical S/PDIF out port at back panel
- Sonic Radar II
Storage
Intel® H170 Express Chipset with RAID 0, 1, 5, 10 and Intel® Rapid Storage
Technology 14 support
- 1 x SATA Express port (gray, compatible with 2 x SATA 6.0 Gb/s ports)
- 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices
support (both SATA & PCIe3.0 x4 mode)*
- 4 x SATA 6.0 Gb/s ports (gray)
- Supports Intel® Smart Response Technology, Intel® Rapid Start
Technology**
* When the M.2 Socket 3 is operating in SATA mode, SATA port 1 will be disabled.
** These functions will work depending on the CPU installed.
LAN
Intel® Gigabit LAN
Anti-surge LANGuard
GameFirst technology
USB
ASMedia USB3.1 Controller - supports ASUS USB 3.1 Boost
- 2 x USB 3.1 ports at rear (1 Type-A, red; 1 Type-C, black)
Intel® H170 Express Chipset - supports ASUS USB 3.1 Boost
- 6 x USB 3.0/2.0 ports (4 ports at mid-board; 2 ports at back panel, blue)
- 8 x USB 2.0/1.1 ports (6 ports at mid-board; 2 ports at back panel, black)*
* 2 x USB2.0 port at mid-board share with ROG extension (ROG_EXT) port.
ASUS unique
features
Gamer’s Guardian
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on VGA, LAN, Audio, KBMS and USB3.0/2.0 Ports
- Highly Durable Components
- Stainless Steel Back I/O
- Q-Design (Q-DIMM, Q-Slot, Q-Shield, Q-LED)
Performance Level Up
- DIGI+ VRM
- AI Suite 3
- Fan Xpert 3 featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
- UEFI BIOS (CrashFree BIOS 3, EZ Flash 3)
- RAMCache: Speed your game loads
