Asus h170 pro gaming [6/93] Package contents
![Asus h170 pro gaming [6/93] Package contents](/views2/1162402/page6/bg6.png)
vi
H170 PRO GAMING specifications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS H170 PRO GAMING motherboard
Cables
4 x Serial ATA 6.0 Gb/s Cables
Accessories
1 x I/O Shield
1 x M.2 Screw Package
1 x PRO GAMING Cable Labels
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for Intel
®
6th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
H170 Express Chipset
Memory
4 x DIMM, max. 64GB DDR4 2133 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please
refer to Memory QVL (Qualified Vendors List) for details.
** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort, HDMI, DVI, D-Sub ports
- Supports DisplayPort with max. resolution 4096 x 2304 @60Hz
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @24MHz
- Supports DVI with maximum resolution of 1920 x 1200 @60Hz
- Supports D-Sub with maximum resolution of 1920 x 1200 @60Hz
- Supports up to three displays simultaneously
Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology,
Insider™
Maximum shared memory of 512 MB
Expansion
slots
1 x PCI Express 3.0 x16 slot (at x16 mode)
1 x PCI Express 3.0 x16 slot (max. at x4 mode, compatible with PCIe x1 and x4
devices. When PCIEX1_2 or PCIEX1_3 is occupied by x1 device,PCIEX16_2
will be at x2 mode)
4 x PCI Express 3.0 x1 slots
