Chapter 1: Product Introduction
1-2
*ASUS System Web-based Management
If any of the above items is damaged or missing, contact your retailer.
1.1 System package contents
Check your system package for the following items.
Model Name
RS300-E9-PS4, RS300-E9-RS4
Chassis
ASUS R10E 1U Rackmount Chassis
Motherboard
ASUS P10S-C/4L/SYS Server Board
Component
1 x 400W Single Power Supply (RS300-E9-PS4)
1 x 450W Redundant Power Supply (RS300-E9-RS4)
4 x Hot-swap 3.5” HDD trays
1 x SAS/SATA Backplane (BP4LX12G-35-R10E)
1 x PCI Riser Card (RE16LE8R-R10A)
1 x Front I/O Board (FPB-R20D)
4 x System Fans (40 mm x 28 mm)
Accessories
1 x RS300-E9 Series User’s Guide
1 x ASWM* Enterprise User’s Guide
1 x ASMB8 User’s Guide (if ASMB8-iKVM is selected)
1 x RS300-E9 Series Support DVD
1 x ASWM* Enterprise DVD
1 x ASMB8 DVD (if ASMB8-iKVM is selected)
1 x Bag of Screws
1 x AC Power Cable (RS300-E9-PS4)
2 x AC Power Cable (RS300-E9-RS4)
Optional Items
1 x CPU Heatsink
ASUS ASMB8-iKVM Remote management card
DVD-ROM/DVD-RW
Second 450W Redundant Power Supply Module (RS300-E9-RS4)
1 x Friction Rail Kit
