Brief:

WF2533

300Mbps Wireless N High Power Router

Easy Network, Trustable

Features:

>Incredible wireless high speed up to 300Mbps

>High transmission power to boost wireless signal for further distance

>Enhanced signal strength to penetrate walls and eliminate Wi-Fi dead zones

>3 * high gain 5dBi detachable antenna design allowing for flexible antenna upgrades

>Various WAN connection types in AP Router mode- DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access (Russia PPPoE/PPTP/L2TP), WISP

>Multiple wireless modes- AP, Repeater, AP+WDS, WDS, Client

>Multi-SSID providing up to 3 additional separate networks for guests and friends

>Easy wireless security setup at a push of the WPS button

>Turbo button to improve the signal strength in a snap

>Intelligent bandwidth control to manage the bandwidth usage for each computer reasonably

>Internet Access Control- IP filtering, MAC Filtering, Domain Filtering based on time

>Quick setup, with built-in multilingual management page

Wireless Security

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Up to 300Mbps

2.4-2.4835GHz

<20dBm(For countries using CE Standards) <27dBm( For countries using FCC Standards)

802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)

20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)

801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)

802.11b: (11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

AP, Repeater, AP+WDS, WDS, Client

64/128-bit WEP WPA-PSK/WPA2-PSK (TKIP/AES)

SSID Broadcast Enable/Disable Wireless MAC Filtering

Wireless

Standards

Signal Rate

Frequency Range

Transmit Power

Data Transfer Rates

Wireless Modes

IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX

1 * 10/100Mbps Auto MDI/MDIX RJ45 LAN port 4 * 10/100Mbps Auto MDI/MDIX RJ45 LAN port

PWR, Turbo, WAN, LAN1-LAN4

(Turbo LED Status: Blue for Normal Power, Red for High Power)

Turbo, Default, WPS

3* 5dBi Detachable Antenna, SMA Connector

DC 12V/1A (Output)

DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access, WISP

Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port

WMM, Bandwidth Control

IP/MAC/Domain Filtering

PPTP, L2TP, IPSec

Multiple SSID, Dynamic DNS, Static Routing, WOL

Hardware

Software

FCC, CE

Others

Certification

Standards

WAN Type

Port Forwarding

QoS

Access Control

VPN Pass-through

Others

Interfaces

LED Indicators

Buttons

Antennas

Power Supply

Environment

Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃

Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing

Specifications are subject to change without notice. Netisis a registered trademark of Netis Systems Co., Ltd. Other brands and product names are trademarks or

registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such

as translation, transformation, or adaptation without permission fromNetis Systems Co., Ltd.

WF2533

300Mbps Wireless N High Power Router
