87045 LIMOGES Cedex
Phone number : (+33) 05 55 06 87 87 - Fax : (+33) 05 55 06 88 88
INDEX Page
1. General specifications ...........................1
2. Technical specifications ......................... 2
3 104 19
TRIMOD HE 40 kVA
The Legrand TRIMOD HE 40 is an UPS on line double conversion
with PWM Hi-Frequency technology. It has passing trough neutral and
Modular Architecture with the possibility to have N+X redundancy.
The nominal power is 40 kVA – 40 kW.
Batteries are lead acid, sealed, free maintenance, valve regulated,
and arranged, inside the UPS or external battery cabinet, in
dedicated Drawers, in order to guarantee compact dimensions
reducing weights and DC voltage level.
1.1 Modularity
The UPS TRIMOD HE 40 has modular architecture, it is composed by
identical modules which work in parallel. Modules are:
• PowerModules6,7kVA;
• BatteryDrawersoffivebatteries(7.2Ahor9Ah).
These modules are installed inside the UPS and have identical
functions.
Power Modules are composed by the following circuits:
• Rectifier/PFC
• Inverter
• BatteryCharger
• CommandLogiccircuit
• AutomaticBy-pass
Battery drawers contain 5 batteries, and are easy to be move and
replace.
1.2 Adaptabilty
The UPS can be easily configured on site, by the user, to work as
three-phase or single phase either in input than output.
1.3 Scalability
ThemodularityofTRIMODUPSallowstoexecutePowerand
Autonomy upgrade. Thanks to the intelligent Plug N’ Play connection,
no HW and SW settings are needed to increase or decrease the
power or the autonomy.
1.4 Redundancy
The modularity of the UPS allows the N+X redundant configurations.
TheRedundacyisachievedusingmoremodulesthanneeded,
modules will run in “load sharing”.
1.5 Architecture
The UPS TRIMOD HE 40 is three–phase input and output, the
architecture is distributed parallel architecture in each phase (there
are more modules in the same phase).
In case of redundant configuration, whenever one module fails, the
other modules in the same phase will guarantee the Energy supply
and protection to the load. The available power in each phase will be
always the sum of the power of the modules installed in that phase.
1. GENERAL SPECIFICATIONS
1.6 By-pass
In each Power Module there is a static By-pass system which, in case
of overload or other anomaly, automatically transfer the load to the
mains.
A dedicated software of remote monitoring and management,
installed on a PC connected to the UPS, allows to check and set all
workingparametersofTRIMODHE(thesamefunctionsavailableon
the UPS control panel) and, furthermore, to schedule and program
computer remote shutdown.
Optional software (UPS SuperviSor) or Net Interface card
(CS121 SK) allow the multi server shutdown and UPS remote control
on the LAN.
TRIMODHEiscontrolledbyamainmicroprocessorwhichworks
togetherwithmicroprocessorsineachpowermodules;Bydisplayis
possible to check all measurements, working parameters and status
of the system.
Here follow the measurements and working parameters available on
the display:
Technicalsheet:UPS-LGR-0066/GB 01/10/2013Lastupdate:01/10/2013
1/2
Input
Current:
• RMSvalue
• Peakvalue
• CrestFactor
Voltage:
• Ph-NRMSvalue
• Ph-PhRMSvalue
Power:
• Nominal(VA)
• Active(W)
Power Factor
Frequency
Output
Current:
• RMSvalue
• Peakvalue
• CrestFactor
Voltage:
• Ph-NRMSvalue
• Ph-PhRMSvalue
Power:
• Nominal(VA)
• Active(W)
Power Factor
Frequency
Batteries
• Voltage
• Capacity
• Current
• Historydata
• ResidualCapacity
• Chargingstatus
Misc.
• InternalTemperature
• FanSpeed
• HVDCBUSVoltage
DATA LOG.
• By-passintervention
• Overheats
• Overloads
• Batteryinterventions
• Totaldischarge
• Events(info,warning,critical)
• Alarms
