Technicalsheet:UPS-LGR-0066/GB Lastupdate:01/10/2013
3 104 19
TRIMOD HE 40 kVA
01/10/2013
2/2
1. GENERAL SPECIFICATIONS (continue)
Output
• Voltage
• Frequency
• Phasesconfiguration
Input
• Enablefreq.synchronizing
(PLL)
• Extendedsynchronizingrange
(Extended PLL)
By-Pass
• Enabling
• Forced
• DIPSpeed
• Off-lineMode
• EPSMode
Batteries
• StartuponBattery
• Thresholdvalue
• Autorestart
• MaxTimeonbattery
The UPS allows also the following settings by display:
2. TECHNICAL SPECIFICATIONS
General Specifications
UPS Topology On line double conversion VFI SS 111
Architecture of the UPS
Modular, scalable, redundant based
on 6,7 kVA Power Modules
In/OutphaseConfiguration Three phase-Three phase
Neutral Neutral Passing through
Output wave form on mains run Sinusoidal
Output wave form on battery run Sinusoidal
Bypass type
Automatic by-pass (static and electromechanic)
& Manual maintenance by-pass
Transfer time Zero
Input
Nominal Voltage 380, 400, 415 3F+N+PE
Voltage range
400V -20% +15%
230V -20% +15%
Frequency
45-65Hz
(43,0÷68,4hz)
THDI
in
< 3%
Power Factor 1
Output with mains (AC-AC)
Nominal voltage 380, 400, 415 3F+N+PE
Nominal power 40.000 VA
Active power 40.000 W
Efficiency (VFI) upto96%
Voltage variation (static) ± 1%
Voltagevariation(dynamic0-100%;100-0%) ± 1%
THDv on nominal power (linear load) < 1 %
THDv on nominal power
(not linear load P.F.=0,7)
< 1 %
Frequency
50/60Hzuseradjustable+/-2%(Standard),
+/-14%(Extended)
Frequency tolerance
Synchronizedwithinputfrequency
or ± 1% free run
Current Crest Factor 3:1
Overload capability:
•for10minutes
•for60seconds
115% load rate with no bypass intervention
135% load rate with no bypass intervention
Battery
Type
LeadAcid,sealed,freemaintenanceVRLA
(on request longlife battery)
Unit Capacity 7,2or9Ah(12V)
Nominal UPS Battery Voltage 240 Volt DC
Battery charger type PWM hi efficiency, one in each power module
Charging Cycle
Smart Charger technology, advanced three
charging steps
Max Charging Current 2,5 A each power module
Environmental specs
Noise level @ 1m 46 dBA
Working temperature range from 0°C to +40°C
Stock temperature range from -20°C to +50°C (excluded batteries)
Humidity range 0-95%notcondensing
Protection degree IP21
Mechanical an Miscellaneous
Net Weight without batteries
1
146 kg
Dimensions (WxHxD)
2
1 x (414 x 1370 x 628) (mm)
Colour RAL7016
Technologyrectifier/booster/inverter MOSFET/IGBT
Communication Interface
2serialportRS232,1logiclevelport,
5 outputs with dry contacts, 1 optional interface slot
Input/Outputconnections 3P + N + PE Connectors on omega bar
Number of Installed Power Modules 6 of 6700 VA
Standards EN 62040-1, EN 62040-2, EN 62040-3
TheUPSTRIMODhastheCEMarkaccordinglywiththeEU
Directives2006/95,2004/108anditcomplywithfollowingstandards:
• EN62040-1“Generalrulesforelectricsafety”
• EN62040-2“Electromagneticcompatibilityandimmunity(EMC)”
• EN62040-3“Performancesandtestingrules”
1
The weigh depends by the number of the installed batteries accordingly with the required
autonomy.
2
The battery cabinet dimension can change depending battery set accordingly with the
required autonomy.
Output in battery Run (DC-AC)
Nominal voltage 380, 400, 415 3F+N+PE
Nominal power 40.000 VA
Active power 40.000 W
Voltage variation (static) ± 1%
Voltagevariation(dynamic0-100%;100-0%) ± 1%
THDv on nominal power (linear load) < 1 %
THDv on nominal power
(not linear load P.F.=0,7)
< 1 %
Frequency 50Hzo60Hz(autosensingorselectable)
Frequency tolerance ± 1% free run
Current Crest Factor 3:1 accordingly with IEC 62 040-3
Overload capability:
•for10minutes
•for60seconds
115%
135%
