Canon DR-2020U [11/40] Moving the scanner
![Canon DR-2020U [11/40] Moving the scanner](/views2/1165702/page11/bgb.png)
7
Moving the Scanner
● Before moving the scanner, make sure to turn the power switch
OFF, and disconnect the power plug from the power outlet.
● When moving the scanner, make sure to lock the lock switch and
carry the scanner with both hands so as not to drop it. The scanner
weighs approximately 7.8 kg.
● When using the scanner, make sure to release the lock switch. If
you use the scanner while the lock switch is locked, an error will
appear on the display panel.
● Make sure to disconnect any interface cables and the AC adapter
when moving the scanner. If the scanner is carried with these items
connected, the plugs and connectors may be damaged or cause
the scanner to fall and result in personal injury or damage to the
scanner.
Handling
WARNING
Note the following precautions whenever using the scanner. Failure to
do so may result in a fire or electric shock.
● Never place alcohol, benzene, paint thinner, aerosol sprays, or any
other flammable substances near the scanner.
● Do not cut, damage, or modify the power cord. Do not place heavy
objects on the power cord, and do not pull or excessively bend the
power cord.
● Never connect the power cord when your hands are wet.
● Do not connect the scanner to a multiplug power strip.
● Do not knot or coil the power cord, as this may result in a fire or
electric shock. When connecting the power cord, make sure that the
power plug is securely and completely inserted into the power
outlet.
● To use a reel-type extension cord, unwind all of the cord from the
reel. Long-term operation with the cord wound on the reel may
cause the cord to overheat and may cause a fire.
● Do not use power cords or AC adapters other than the power cord
and AC adapter provided with this scanner.
● Do not attempt to dismantle the scanner or modify it in any way, as
this is dangerous and may lead to a fire or electric shock.
● Never attempt to dismantle or modify the AC adapter in any way, as
doing so is dangerous.
● Do not use flammable aerosol spray products near the scanner.
● When cleaning the scanner, turn the power switch OFF and
disconnect the power cord from the power supply.
● Clean the scanner using a slightly dampened cloth that has been
well wrung out. Never use alcohol, benzene, paint thinner, or any
other flammable substance.
● Disconnect the power cord from the power outlet regularly, and
clean the area around the base of the power plug’s metal pins and
the power outlet with a dry cloth to ensure that all dust and grime is
removed. If the power cord is connected for a long period of time in
a damp, dusty, or smoky location, dust can build up around the
power plug and become damp. This may cause a short circuit and
result in a fire.
● If the scanner makes strange noises, or gives off smoke, heat or
strange odors, or the scanner does not function or other
abnormalities occur when you use the scanner, immediately turn
the power switch OFF and disconnect the power plug from the
power outlet. Then, contact your local authorized Canon dealer or
service representative for further information.
● Do not drop the scanner, or subject it to impact or strong shock.
Should the scanner ever become damaged, immediately turn the
power switch OFF, and disconnect the power plug from the power
outlet. Then, contact your local authorized Canon dealer or service
representative to have the unit serviced.
● Notice to Cardiac Pacemaker Users:
This product generates a weak magnetic field. If you use a cardiac
pacemaker, move away from the product in the event that you
notice any unusual symptoms. Also, please consult a cardiologist.
Lock switch
