Concord transformer pro [10/19] Warning

42 43

P2 Harness guide

P3 Stabilisers

_ USiNG THE CONCOrD PrOTECTOr (FrOM 9 TO 18 KG)

P1Attachmenthooks

WArNiNG!

• TheCONCORDPROTECTORmayonlybeusedinconjunctionwiththe

CONCORD TRANSFORMER PRO.

• TheCONCORDTRANSFORMERPROcanbeusedwithouttheCONCORD

 PROTECTOR,oncethechildhasreachedabout4yearsofageor

 approx.15kgbodyweight.

CAUTiON!

• Ensurethatthestabilisors(P3)arepositionedcorrectlyintheharnessguides(03)

of the CONCORD TRANSFORMER!

• TheCONCORDPROTECTORmustnotbeattachedatanangle,askew

or back to front!

Mount the CONCORD TRANSFORMER on the vehicle seat as described in the user

manual.

Placeyourchildontotheseatofthe

CONCORD TRANSFORMER as far back

as possible.

Place the CONCORD PROTECTOR onto

the CONCORD TRANSFORMER so

that the stabilisers (P3) are level with the

harness guides (03) of the CONCORD

TRANSFORMER.

Pushtherestrainingbodybackwardsuntil

the stabilisors (P3) are flush with the red

markingsontheharnessguide.
