Gigabyte ga-z97m-ds3h [4/40] Box contents
![Gigabyte ga-z97m-ds3h [4/40] Box contents](/views2/1167845/page4/bg4.png)
- 4 -
GA-Z97M-DS3H Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-Z97M-DS3H motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS_USB
CPU_FAN
ATX_12V_2X4
ATX
F_AUDIO
AUDIO
B_BIOS
DDR3_2
DDR3_1
DDR3_4
DDR3_3
BAT
F_PANEL
COM
Intel
®
Z97
CLR_CMOS
M_BIOS
PCIEX1_1
PCIEX16
LGA1150
GA-Z97M-DS3H
DVI
VGA
HDMI
R_USB30
USB30_LAN
Realtek
®
GbE LAN
F_USB30
PCIEX1_2
SATA3
iTE
®
Super I/O
F_USB2
LPT
3 5
2 4
SYS_FAN
PCIe to
PCI Bridge
F_USB1
SATA3
0 1
