Removing inner glass

To remove the inner pane, screw out the screw

and open the plastic latches

2 located in the upper

corners of the door. Now pull the glass carefully to

set it free from the second blocking device. Take

the glass out. Insert the clean glass back carefully

and lock it by means of the blocking device.

Replacing the oven light

The oven light 3 should have the following

parameters:

a) temperature resistance – up to 300°C

b) power supply: see V/Hz indicated on data plate.

c) power input: 25W.

d) E 14 connection.

x to prevent damage, put a cloth into the oven

x screw out the glass cover of the light

x screw out the old bulb and replace it with

the new one

x adjust the glass cover and remove the cloth

x connect the appliance to the mains

electricity supply

Fan filter

In case your oven is equipped with the net filter

which protects the fan from the drops of fat, take

out the filter every time you use the oven

intensively and wash it in hot water with washing-up

liquids.

To withdraw the filter, pull the handle

4 upwards.

To mount the filter, insert its ledges into a label on

the wall and carefully pull it downwards. The filter is

fixed at the protective casing of the fan.

Attention! First of all disconnect the

appliance from the power supply.
