The ZyXEL ES1100 Series 8/16/24-port FE Unmanaged Switch is designed for SMBs to boost

business network performance and eciency. The Series provides not only plug-and-play

simplicity for high-bandwidth connectivity, but also N-way auto-negotiation to connect network

counterparts with the highest possible data speed and to activate duplex mode automatically.

The ES1100 Series is ideal for typical noise-sensitive oce environments for its superior energy

eciency and Ethernet connectivity.The ZyXEL ES1100 Series consists of four Fast Ethernet

switches and two Power over Ethernet (PoE) switches: the ES1100-16, ES1100-24, ES1100-24E,

ES1100-24G, ES1100-8P and ES1100-16P. The desktop design of the ES1100-8P/16P/16/24E is

ideal for SB or SOHO users seeking reliable network connectivity, while the ES1100-24/24G is

designed for 19” racks, making it easy to be deployed in standard wiring closets.

Benets

Green networking

The environment-aware ZyXEL ES1100 Series oers 10/100 Mbps Ethernet speeds that is critical to next-

generation network applications. It also provides power-saving functions to reduce energy consumption

for lowered operating costs.

Trac detection — IEEE Energy Ecient Ethernet (EEE) compliance (ES1100-8P/16P/16/24E/24)

The IEEE Energy Ecient Ethernet (EEE) feature automatically detects network trac and adjusts power

consumption dynamically, enabling the switch to reduce power consumption during low link utilization

periods.

Inactive link detection

The inactive link detection function automatically reduces power usage when inactive links or devices

are detected. The ZyXEL ES1100 Series can adjust power consumption according to link status and the

number of active network devices.

Cable length detection

This green feature enables the switch to automatically detect the length of connected Ethernet cables

and adjust power usage accordingly. The shorter the cable length, the less power it consumes.

• Non-blocking, wire-speed

transmission

• Auto MDI/MDI-X support

• IEEE 802.3az compliant

(ES1100-8P/16P/16/24E/24)

• Fanless design for silent

operation

(ES1100-8P/16/24E/24/24G)

• IEEE 802.3x ow control

supported

• IEEE 802.1p CoS supported

• IEEE 802.3af power on up to

4/8 ports (ES1100-8P/16P)

IEEE 802.3az-compliant Switch with Decent Performance

for Small-group Networks

ES1100 Series

8/16/24-port FE

Unmanaged Switch
