Zyxel GS1100-8HP datasheet онлайн

The ZyXEL GS1100 Series is the best solution for instant Gigabit connectivity in office

environments demanding silent operation and better energy efficiency. With power-saving

functions, Gigabit Ethernet and a fanless design, the GS1100 Series provides plug-and-play

simplicity for high-bandwidth network applications.

The ZyXEL GS1100 Series consists of three unmanaged switches: the GS1100-8HP, GS1100-16

and GS1100-24. The GS1100-16 features 16 GbE ports and the GS1100-24 is a 24-port Gigabit

switch with 2 additional open Gigabit SFP slots. The GS1100-8HP is an 8-port Gigabit switch

that complies with the IEEE 802.3at Power over Ethernet (PoE) Plus standard, providing 4 PoE

ports with up to 30 watts per port.

GS1100 Series

8/16/24-port GbE

Unmanaged Switch

GS1100 Series

8/16/24-port GbE

Unmanaged Switch

■

Non-blocking, wire-speed

transmission

■

Auto MDI/MDI-X support

■

IEEE 802.3az compliant

■

Fanless design for silent

operation

■

IEEE 802.3x flow control

supported

■

IEEE 802.1p CoS supported

■

Jumbo frame support (up to 9 K

bytes)

■

IEEE 802.3at PoE Plus standard

with 30 W per port

(GS1100-8HP)

Key Benefits

Green networking

The GS1100 Series not only offers Gigabit Ethernet connectivity for next-generation network

applications, but also power-saving functions for better energy efficiency. Capable of dynamically

adjusting power output according to traffic, active links and cable length, the GS1100 Series can

reduce energy consumption for lowered operating costs.

Traffic detection — Energy Efficient Ethernet (EEE) compliance

The IEEE 802.3az Energy Efficient Ethernet (EEE) feature automatically detects network traffic and

adjusts power consumption dynamically, enabling the switch to reduce power consumption during

low link utilization periods. The GS1100-8HP is built with an additional IEEE 802.3az on/off button,

which allows users to activate/deactivate Energy Efficient Ethernet mode with a simple push of a

button.

Inactive link detection

The inactive link detection function automatically reduces power usage when inactive links or

devices are detected. The ZyXEL GS1100 Series can adjust power consumption according to link

status and the number of active network devices.

Cable length detection

This green feature enables the switch to automatically detect the length of connected Ethernet

cables and adjust power usage accordingly. The shorter the cable length, the less power it

consumes.

Fanless design

The complete GS1100 Series comes in a fanless design that ensures silent operation in small or quiet

office environments. The GS1100-8HP PoE model is specifically designed with an external power

adapter that eliminates the need for an additional fan to cool down the device, making it perfect for

quiet PoE deployments.

Affordable Solution for Gigabit

Connections to the Desktop
