Zyxel GS1100-8HP [2/2] Gs1100 series

5-100-01012009 06/12

F o r m o r e p r o d u c t i n f o r m a t i o n , v i s i t u s o n t h e w e b a t w w w. Z y X E L . c o m

ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their

respective owners. All specifications are subject to change without notice.

Gigabit to the desktop

The ZyXEL GS1100 Series offers small offices 8/16/24-port Gigabit connectivity at the most competitive price. Additionally, the GS1100-24 model is equipped

with 2 extra SFP slots that enable fiber optic connections for long-distance deployments. With Gigabit network performance and high cost-effectiveness, the

GS1100 Series is the ideal solution for bandwidth-intensive applications such as high-resolution photo transmission, video/audio streaming and server farm

connections.

Freedom of installation via PoE (GS1100-8HP)

The GS1100-8HP supports the IEEE 802.3at PoE Plus standard to ease the installation of network devices in challenging spaces such as ceilings or walls. The

power supply of up to 30 watts per port allows the GS1100-8HP to power PoE-enabled WLAN APs, VoIP phones and IP surveillance cameras through CAT-5

cables of less than 100 meters (300 feet) in length. With the ZyXEL GS1100-8HP, there is no need for extra power adapters in installing PoE devices in difficult

locations. This feature helps enterprises reduce installation time and cost when there are many such devices on the network.

Specifications

Standard Compliance

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100Base-TX Ethernet

• IEEE 802.3ab 1000Base-T Ethernet

• IEEE 802.3az EEE support

• IEEE 802.3x flow control

• IEEE 802.3z 1000Base-X (GS1100-24)

• IEEE 802.1p CoS

• IEEE 802.3at PoE Plus (GS1100-8HP)

GS1100 Series

8/16/24-port GbE Unmanaged

Switch

GS1100 Series

8/16/24-port GbE Unmanaged

Switch

Model GS1100-8HP GS1100-16 GS1100-24

8-port GbE Unmanaged PoE Switch 16-port GbE Unmanaged Switch 24-port GbE Unmanaged Switch

Product name

Port Density

1000Base-T 4 16 24

1000Base-T PoE 4 - -

Open SFP slot (GbE) - - 2

Performance

Switching capacity (Gbps) 16 32 52

Switching forwarding rate (Mpps) 11.9 23.8 38.7

Packet buffer (byte) 256 K 256 K 448 K

MAC address 8 K 8 K 8 K

Jumbo frame (byte) 9 K 9 K 9 K

Auto MDI/MDI-X Yes Yes Yes

802.1p CoS Yes Yes Yes

Broadcast storm control Yes Yes Yes

VLAN packet pass-through Yes Yes Yes

Power

Input voltage 54 V DC, 1.66 A 100 - 240 V AC, 50/60 Hz 100 - 240 V AC, 50/60 Hz

Power supply External Internal Internal

Maximum power consumption (watt) 90 6.4 16.2

PoE power budget (watt) 75 - -

Physical Specifications

Dimensions (WxDxH) (mm/in.) 210 x 104 x 27/8.27 x 4.09 x 1.06 215 x 133 x 42/8.46 x 5.24 x 1.65 441 x 131 x 44/17.36 x 5.16 x 1.73

Weight (kg/lb.) 0.54/1.19 1/2.20 2/4.41

Environmental Specifications

Operating temperature 0°C to 50°C/32°F to 122°F

Storage temperature -40°C to 70°C/-40°F to 158°F

Operating humidity 10% to 95% (Non-condensing)

Safety Agency Certification

• UL 60950-1

• EN 60950-1

• IEC 60950-1

• EU RoHS compliant
