3
Specications
Model ES1100-8P ES1100-16P ES1100-16 ES1100-24E ES1100-24 ES1100-24G
Product name
8-port FE
Unmanaged
PoE Switch
16-port FE
Unmanaged
PoE Switch
16-port FE
Unmanaged
Switch
24-port FE
Unmanaged
Switch
24-port FE
Unmanaged
Switch
24-port FE
Unmanaged
Switch
Port Density
1000BASE-T 4 8 16 24 24 44
1000BASE-T PoE 4 8 - - - -
Dual personality GbE ports - - - - - 2
Performance
Switching capacity (Gbps) 1.6 3.2 3.2 4.8 4.8 8.8
Switching forwarding rate (Mpps) 1.2 2.4 2.4 3.6 3.6 6.6
Packet buffer (Bytes) 96K 160K 256K 256K 256K 320K
MAC address 1k 8k 8k 8k 8k 8k
Jumbo frame support (up to 2048 Bytes) - - Yes Yes Yes -
802.3x flow control prioritization Yes Yes Yes Yes Yes Yes
802.1p CoS Yes Yes Yes Yes Yes Yes
Back-pressure-based flow control Yes Yes Yes Yes Yes Yes
Loop detection - - Yes Yes Yes -
Auto MDI/MDI-X Yes Yes Yes Yes Yes Yes
Power Requirement
Input voltage of AC 100 - 240 V AC, 50/60 Hz
Maximum power consumption (Watt) 64 130 - - - -
Physical Specifications
Fanless Yes - Yes Yes Yes Yes
Item dimensions (WxDxH)(mm/in.)
262 x 184 x 41/
10.31 x 7.24 x
1.61
262 x 184 x 41/
10.31 x 7.24 x
1.61
216 x 133 x 42/
8.50 x 5.24 x
1.65
267 x 162 x 42/
10.51 x 6.38 x
1.65
441 x 131 x 44/
17.36 x 5.16 x
1.73
441 x 131 x 44/
17.36 x 5.16 x
1.73
Item weight (kg/lb.) 1.4/3.09 1.7/3.75 0.77/1.70 1.28/2.82 1.35/2.98 1.5/3.31
Packing dimensions (WxDxH)(mm/in.)
318 x 275 x 73/
12.52 x 10.83 x
2.87
318 x 275 x 73/
12.52 x 10.83 x
2.87
325 x 227 x 71/
12.80 x 8.94 x
2.80
325 x 227 x 71/
12.80 x 8.94 x
2.80
477 x 222 x 71/
18.78 x 8.74 x
2.80
477 x 222 x 71/
18.78 x 8.74 x
2.80
Packing weight (kg/lb.) 2.2/4.85 2.5/5.51 1.59/3.51 2.1/4.63 2.14/4.72 2.2/4.85
Environmental Specifications
Operating temperature 0°C to 50°C/32°F to 122°F
Storage temperature -40°C to 70°C/-40°F to 158°F
Operating humidity 10% to 95% (non-condensing)
MTBF (hr) 164,603 75,888 322,400 100,833 295,895 100,833
Heat dissipation (BTU/hr) 255.41 551.06 8.18 13.3 13.3 50.13
ES1100 Series
8/16/24-port FE Unmanaged Switch
Features
Standard Compliance
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Ethernet (ES1100-
24G)
• IEEE 802.3af PoE (ES1100-8P/16P)
• IEEE 802.3x ow control and back-pressure
• IEEE 802.1p CoS
• IEEE 802.3az EEE (ES1100-8P/16P/16/24E/24)
Certication
Safety
• EN 60950-1
• IEC 60950-1
• EU RoHS compliant
Emission (EMC)
• FCC Part 15 (Class A)
• CE EMC (Class A)
Green Features
• Energy Ecient Ethernet for reduced power
consumption in low-trac periods
(ES1100-8P/16P/16/24E/24)
• Inactive link detection for dynamic power
output adjustment
• Adjusts power usage according to the length
of connected Ethernet cables
• Easy device power-o with the power on/o
switch
