2
GB
Installation
- Plaster and tile the wall, excluding the area occupied by the
mounting template. Seal any apertures in the wall so that
they are watertight to spray water.
• Tiles laid in mortar should be pointed so that the joint
is tapered towards the outside.
• Seal prefabricated walls with a permanently plastic
compound.
Installation of functional elements, see fold-out page I,
Figs. [1] to [4].
Shut off cold and hot water supplies.
1. Remove the mounting template, see fold-out page I, Fig. [1].
2. Unscrew closure plug (A) and plug (B), see Fig. [2].
3. Screw in sound absorber (C), see Fig. [3].
4. Grease O-ring of race (D) with the special grease supplied.
Install race (D); there is only one possible position,
see detail, Fig. [3].
5. Grease O-ring of adapter (E) with the special grease
supplied. Fasten adapter (E), see Fig. [4].
6. Install Aquadimmer (F); there is only one possible position,
see detail, Fig. [4].
Open cold and hot-water supply and check connections
for water-tightness.
Installation of escutcheon (L) and shut-off handle (N),
see fold-out page II, Figs. [5] to [7].
1. Attach sleeve (H), bracket (I) and sleeve (I1), see fold-out
page II, Fig. [5].
2. Grease seals (L1) of escutcheon mounting base (L2) with
the special grease supplied, push on escutcheon mounting
base (L2) and fasten with screws (M), see Fig. [6].
3. Attach escutcheon (L).
4. Attach stop ring (G) so that marking (G1) is at the top,
see Fig. [7].
5. Attach splined adapter (J); the faces (J1) coincide in only
one position and turn splined adapter (J) so that the
arrow (J2) points upwards.
6. Screw in mounting set (O).
7. Attach shut-off handle (N) so that marking (N1) is at the top.
If the thermostat has been installed at too great a depth,
this can be increased by 27.5mm with an extension set
(see Replacement parts, fold-out page I, Prod. no.: 47 781).
Operating shut-off handle (N)
Shut-off handle in central position = closed
Turn shut-off handle clockwise = discharge from spout
Turn shut-off handle anti-clockwise = discharge from shower
Reversed connection (hot on right - cold on left).
Replace thermostatic compact cartridge (W), see
Replacement parts, fold-out page I, Prod. no.: 47 186 (3/4”).
Adjusting
Installation of the temperature control handle (R) and
temperature adjustment, see fold-out page II, Figs. [8] and [9].
• Before the mixer is put into service, if the mixed water
temperature measured at the point of discharge varies from
the specified temperature set on the thermostat.
• After any maintenance operation on the thermostatic
cartridge.
1. Open the shut-off valve and check the temperature of the
water with a thermometer, see Fig. [8].
2. Turn the regulating nut (Q) clockwise or anticlockwise until
the water temperature reaches 38 °C.
3. Screw in mounting set (S), see Fig. [9].
4. Install temperature control handle (R) so that button (V) is at
the top.
Temperature limitation
The safety stop limits the temperature range to 38 °C.
If a higher temperature is desired, the 38 °C limit can be
overridden by pressing button (V), see Fig. [9].
Temperature end stop
If the temperature end stop is at 43 °C, use handle with
Prod. no.: 47 812 (see Replacement parts fold-out page I).
Prevention of frost damage
When the domestic water system is drained, thermostats must
be drained separately, since non-return valves are installed in
the hot and cold water connections.
The complete thermostat assemblies and non-return valves
must be unscrewed and removed.
Maintenance
Inspect and clean all parts, replace as necessary and lubricate
with special grease.
Shut off cold and hot water supplies.
I. Thermostatic compact cartridge (W), see fold-out page II,
Figs. [10], [11] and [12].
• Loosen screw ring (Y) using a 34mm tool.
• If necessary, lever out thermostatic compact cartridge (W)
via recess (W1).
• Unscrew screw ring (Y).
Assemble in reverse order.
Observe the correct installation position of thermostatic
compact cartridge (W), see detail (W2).
Readjustment is necessary after every maintenance operation
on the thermostatic cartridge (see Adjusting).
II. Non-return valve (X), see fold-out page II, Figs. [10], [11]
and [13].
Assemble in reverse order.
Observe the correct installation positions.
III. Aquadimmer (Z), see fold-out page II, Figs. [10], [11]
and [13].
Assemble in reverse order.
Observe the correct installation positions.
Replacement parts, see fold-out page I (* = special
accessories).
Care
For directions on the care of this fitting, refer to the
accompanying Care Instructions.
Always take care with the concealed mixer
housing, see fold-out page I.
