![Zyxel GS1900-48HP [182/230] The global screen](/views2/1168576/page182/bgb6.png)
Chapter 28 Configuration: Security
GS1900 Series User’s Guide
182
28.4 802.1X
28.4.1 The Global Screen
Use this screen to view the Global settings. Click Configuration > Security > 802.1X > Global
to open this screen.
Figure 172 Configuration > Security > 802.1X > Global
The following table describes the labels in this screen.
28.4.2 The Port Screen
Use this screen to view the Port settings. Click Configuration > Security > 802.1X > Port to
open this screen.
State Select Enable or Disable for the Protected Port status.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
Table 138 Configuration > Security > Port Security > Port > Edit (continued)
LABEL DESCRIPTION
Table 139 Configuration > Security > 802.1X > Global
LABEL DESCRIPTION
Global
802.1X Select the 802.1X security setting to be enabled or disabled.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
