GS1900 Series User’s Guide 54
CHAPTER 7
Monitor: Port
7.1 Overview
This section provides information for Port in Monitor. Use the Port screens to view general Switch
port settings.
7.1.1 What You Can Do in this Chapter
•The Port screen (Section 7.2 on page 54) displays status, port counters, and bandwidth
utilization.
•The PoE screen (Section 7.3 on page 58) displays PoE.
•The Bandwidth Management screen (Section 7.4 on page 59) displays bandwidth control.
•The Storm Control screen (Section 7.5 on page 60) displays port settings of the Switch.
7.2 Port
Use this screen to view Switch port settings.
7.2.1 Status
Use this screen to view the Switch’s port statistics. Click Monitor > Port > Port > Status to
access this screen.
Figure 47 Monitor > Port > Port > Status
Each field is described in the following table.
Table 22 Monitor > Port > Port > Status
LABEL DESCRIPTION
Port This is the port index number.
Port Name A descriptive name that identifies this port.
