Chapter 5 Getting Start

GS1900 Series User’s Guide

Figure 37 Getting Start > VLAN > 1 Step 1 Create VLAN

Each field is described in the following table.

After clicking Next, the tag VLAN setting screen appears.

Figure 38 Getting Start > VLAN > 2 Step 2 Tag VLAN Setting

Table 12 Getting Start > VLAN > 1 Step 1 Create VLAN

LABEL DESCRIPTION

Create VLAN ID (1-

4094)

Type a number between 1 and 4094 to create a VLAN ID.

Edit VLAN ID Select from the drop-box a VLAN ID.

Next Click Next to show the next screen.
