Chapter 1 Introduction
ZyWALL USG 20-2000 User’s Guide
14
Configuration Menu
Use the configuration menu screens to configure the ZyWALL’s features.
Table 5 Configuration Menu Screens Summary
FOLDER OR LINK TAB FUNCTION
Quick Setup Quickly configure WAN interfaces or VPN connections.
Licensing
Registration Registration Register the device and activate trial services.
Service View the licensed service status and upgrade licensed services.
Signature
Update
Anti-Virus Update anti-virus signatures immediately or by a schedule.
IDP/AppPatrol Update IDP signatures immediately or by a schedule.
System Protect View system-protect signatures status.
Network
Interface Port Grouping Configure physical port groups.
Port Role Use this screen to set the ZyWALL’s flexible ports as LAN1, WLAN,
or DMZ.
Ethernet Manage Ethernet interfaces and virtual Ethernet interfaces.
PPP Create and manage PPPoE and PPTP interfaces.
Cellular Configure a cellular Internet connection for an installed 3G card.
Tunnel Configure tunneling between IPv4 and IPv6 networks.
WLAN Configure settings for an installed wireless LAN card.
VLAN Create and manage VLAN interfaces and virtual VLAN interfaces.
Bridge Create and manage bridges and virtual bridge interfaces.
Auxiliary Manage the AUX port.
Trunk Create and manage trunks (groups of interfaces) for load balancing
and link High Availability (HA).
Routing Policy Route Create and manage routing policies.
Static Route Create and manage IP static routing information.
RIP Configure device-level RIP settings.
OSPF Configure device-level OSPF settings, including areas and virtual
links.
Zone Configure zones used to define various policies.
DDNS Profile Define and manage the ZyWALL’s DDNS domain names.
NAT Set up and manage port forwarding rules.
HTTP Redirect Set up and manage HTTP redirection rules.
ALG Configure SIP, H.323, and FTP pass-through settings.
IP/MAC
Binding
Summary Configure IP to MAC address bindings for devices connected to
each supported interface.
Exempt List Configure ranges of IP addresses to which the ZyWALL does not
apply IP/MAC binding.
DNS Inbound
LB
DNS Load
Balancing
Configure DNS Load Balancing.
Auth. Policy Define rules to force user authentication.
Firewall Firewall Create and manage level-3 traffic rules.
Session Limit Limit the number of concurrent client NAT/firewall sessions.
