Chapter 1 Introduction

ZyWALL USG 20-2000 User’s Guide

1.7 Wall-mounting

See Table 1 on page 5 for the ZyWALL USG models that can be wall-mounted. Do the following to

attach your ZyWALL to a wall.

1 Screw two screws with 6 mm ~ 8 mm (0.24" ~ 0.31") wide heads into the wall 150 mm apart (see

the figure in step 2). Do not screw the screws all the way in to the wall; leave a small gap between

the head of the screw and the wall.

The gap must be big enough for the screw heads to slide into the screw slots and the connection

cables to run down the back of the ZyWALL.

Note: Make sure the screws are securely fixed to the wall and strong enough to hold the

weight of the ZyWALL with the connection cables.

2 Use the holes on the bottom of the ZyWALL to hang the ZyWALL on the screws.
