Chapter 59 SNMP Server Commands
Ethernet Switch CLI Reference Guide
210
snmp-server trap-destination
<ip> [udp-port <socket-number>]
[version <v1|v2c|v3>] [username
<name>]
Sets the IP addresses of up to four SNMP managers (stations
to send your SNMP traps to). You can configure up to four
managers.
C13
no snmp-server trap-destination
<ip>
Deletes the specified SNMP manager. C 13
snmp-server username <name> sec-
level <noauth|auth|priv> [auth
<md5|sha>] [priv <des|aes>]
Sets the authentication level for SNMP v3 user
authentication. Optionally, specifies the authentication and
encryption methods for communication with the SNMP
manager.
name: Must match an existing account on the Switch.
noauth: Use the username as the password string sent to
the SNMP manager. This is equivalent to the Get, Set and
Trap Community in SNMP v2c. This is the lowest security
level.
auth: Implement an authentication algorithm for SNMP
messages sent by this user.
priv: Implement authentication and encryption for SNMP
messages sent by this user. This is the highest security level.
Note: The settings on the SNMP manager must be
set at the same security level or higher than
the security level settings on the Switch.
C13
Table 123 snmp-server trap-destination enable traps Command Summary
COMMAND DESCRIPTION M P
snmp-server trap-destination
<ip> enable traps
Enables sending SNMP traps to a manager. C 13
no snmp-server trap-destination
<ip> enable traps
Disables sending of SNMP traps to a manager. C 13
snmp-server trap-destination
<ip> enable traps aaa
Sends all AAA traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps aaa
Prevents the Switch from sending any AAA traps to the
specified manager.
C13
snmp-server trap-destination
<ip> enable traps aaa <options>
Sends the specified AAA traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps aaa <options>
Prevents the Switch from sending the specified AAA traps to
the specified manager.
C13
snmp-server trap-destination
<ip> enable traps interface
Sends all interface traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps interface
Prevents the Switch from sending any interface traps to the
specified manager.
C13
snmp-server trap-destination
<ip> enable traps interface
<options>
Sends the specified interface traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps interface
<options>
Prevents the Switch from sending the specified interface
traps to the specified manager.
C13
Table 122 snmp-server Command Summary (continued)
COMMAND DESCRIPTION M P
