Chapter 7 Bandwidth Commands
Ethernet Switch CLI Reference Guide
42
The following section lists the commands for this feature.
7.2 Command Examples: ingress
This example sets the outgoing traffic bandwidth limit to 5000 Kbps and the incoming traffic
bandwidth limit to 4000 Kbps for port 1.
Table 23 Command Summary: bandwidth-control & bandwidth-limit
COMMAND DESCRIPTION M P
show interfaces config <port-
list> bandwidth-control
Displays the current settings for interface bandwidth control. E 3
bandwidth-control Enables bandwidth control on the Switch. C 13
no bandwidth-control Disables bandwidth control on the Switch. C 13
interface port-channel <port-
list>
Enters subcommand mode for configuring the specified ports. C 13
bandwidth-limit ingress Enables bandwidth limits for incoming traffic on the port(s). C 13
bandwidth-limit ingress
<rate>
Sets the maximum bandwidth allowed for incoming traffic on
the port(s).
C13
bandwidth-limit egress Enables bandwidth limits for outgoing traffic on the port(s). C 13
bandwidth-limit egress
<rate>
Sets the maximum bandwidth allowed for outgoing traffic on
the port(s).
C13
no bandwidth-limit ingress Disables ingress bandwidth limits on the specified port(s). C 13
no bandwidth-limit egress Disables egress bandwidth limits on the specified port(s). C 13
bandwidth-limit cir Enables commit rate limits on the specified port(s). C 13
bandwidth-limit cir <rate> Sets the guaranteed bandwidth allowed for the incoming
traffic flow on a port. The commit rate should be less than the
peak rate. The sum of commit rates cannot be greater than or
equal to the uplink bandwidth.
Note: The sum of CIRs cannot be greater than or
equal to the uplink bandwidth.
C13
bandwidth-limit pir Enables peak rate limits on the specified port(s). C 13
bandwidth-limit pir <rate> Sets the maximum bandwidth allowed for the incoming traffic
flow on the specified port(s).
C13
no bandwidth-limit cir Disables commit rate limits on the specified port(s). C 13
no bandwidth-limit pir Disables peak rate limits on the specified port(s). C 13
sysname# configure
sysname(config)# bandwidth-control
sysname(config)# interface port-channel 1
sysname(config-interface)# bandwidth-limit egress 5000
sysname(config-interface)# bandwidth-limit ingress 4000
sysname(config-interface)# exit
sysname(config)# exit
