Ethernet Switch CLI Reference Guide
83
CHAPTER 17
Error Disable Recovery
Commands
Use these commands to configure the disabled port recovery features on the Switch.
17.1 Disabled Port Recovery Overview
Some features, such as loop guard, allow the Switch to shut down a port when an error is
detected on the port. For example, if the Switch detects that packets sent out the port(s) loop
back to the Switch, the Switch can shut down the port(s) automatically. After that, you need to
enable the port(s) manually via the web configurator or the commands. With disabled port
recovery, you can set the disabled port(s) to become active again after the time interval you
specify.
" If the reason why the port(s) is shut down is still there after the port(s) is
enabled, the port(s) will be shut down again.
17.2 User Input Values
This section lists the common term definition appears in this chapter.
Table 48 errdisable recovery command user input values
USER INPUT DESCRIPTION
reason loopguard
At the time of writing, the loop guard feature allows the Switch to
shut down a port due to errors.
