3. Grip the door on the two outer sides and

close it approximately half way. Pull the

door towards you, lifting it out of its slot (see

diagram). To replace the door, reverse this

sequence.

To remove oven door with soft closing hinges*:

1. Open the door completely.

2. Lift the pull-out hooks located on the two

hinges. If you cannot lift them manually, use

a tool as a lever.

3. Completely rotate downwards the pull-out

hooks.

4. Holding the door by its two outer sides,

slowly close it but not completely. Pull the

door to remove it from its seat (see gure).

To re-assemble the door follow the procedure

in reverse order.

5. Rotate the pull-out hooks upwards until they

touch the front of the oven.

6. Push the pull-out hooks downwards,

making sure they are steady and do not

rotate forward.

Inspecting the seals

Check the door seals around the oven regularly. If the seals are damaged,

please contact your nearest Service Centre (see Assistance). We recommend

that the oven is not used until the seals have been replaced.

Replacing the light bulb

To replace the oven light bulb:

1. Remove the glass cover of the

lamp-holder.

2. Remove the light bulb and replace

it with a similar one: Wattage 25 W,

cap E 14.

3. Replace the glass cover (see

diagram).

! Do not use the oven lamp as/for ambient lighting.

Sliding rack kit assembly

To assemble the sliding racks:

1. Remove the two frames, lifting

them away from the spacers A (see

gure).

2. Choose which shelf to use with the

sliding rack. Paying attention to the

direction in which the sliding rack is

to be extracted, position joint B and

then joint C on the frame.

3. Secure the two frames with the

guide rails using the holes provided

on the oven walls (see diagram).

The holes for the left frame are

situated at the top, while the holes

for the right frame are at the bottom.

4. Finally, fit the frames on the

spacers A.

Left

guide rail

Right guide

rail

Direction

of extraction
