Start-up and use

WARNING! The oven is provided

with a stop system to extract the

racks and prevent them from

coming out of the oven (1).

As shown in the drawing, to extract

them completely, simply lift the

racks, holding them on the front

part, and pull (2).

! The rst time you use your appliance, heat the empty oven with its door closed

at its maximum temperature for at least half an hour. Make sure that the room

is well ventilated before switching the oven off and opening the oven door. The

appliance may emit a slightly unpleasant odour caused by protective substances

used during the manufacturing process burning away.

! To make the setting process easier, keep the knob in position: this will

increase the scrolling speed of the numbers on the display.

! Each setting will automatically be stored in the appliance memory after 10

seconds.

! The touch controls cannot be activated if the user is wearing gloves.

Some models are equipped with a system of hinges which allows the door to

close slowly, without the user having to follow the movement through with his/

her hand. To use the system correctly, before closing the door:

• Open the door fully.

• Do not force the closing movement manually.

! In order to optimise the cooking performance, when starting the selected

function, product settings will be applied that could cause a delayed start of

the fan and heating elements.

Control panel lock

! The control panel can be locked while the oven is off, once cooking has

started or nished and during programming.

To lock the oven controls, press and hold the icon for at least 2 seconds.

A buzzer sounds and the display shows the key symbol “n—O”. The

icon, when lit, indicate lock function activation.

To deactivate the lock, press and hold the icon again for at least 2

seconds.

Setting the clock

! The clock can only be set when the oven is switched off. If the oven is

in standby mode, pressing the icon once will display the current time

setting. Press it again to set the time.

After connection to the power supply network or after a blackout, the

icon and the digits on the display will ash for 10 seconds.

To set the clock:

1. Press the icon.

2. Turn the TIMER knob towards and to adjust the hour value.

3. Once you have reached the correct hour value, press the icon.

4. Repeat the above process to set the minutes.

If a blackout occurs, it will be necessary to reset the clock. If the icon

ashes on the display, this indicates that the clock has not been set correctly.

Setting the minute minder

! The minute minder may still be set whether the oven is switched on or off.

It does not switch the oven on or off.

When the set time has elapsed, the timer emits a buzzer that will automatically

stop after 30 seconds or when any active button on the control panel is

pressed.

To adjust the timer proceed as follows:

1. Press the icon.

2. Adjust the time as desired by turning the TIMER knob towards and .

3. Once you have reached the desired value, press the icon again.

The lit symbol will remind you that the minute minder is on. The DISPLAY

will show the countdown.

To cancel the minute minder, press the icon and use the knob to set the

time to 00:00. Press button again.

The icon will switch off to indicate that the minute minder has been

disabled.

Starting the oven

1. Switch the control panel on by pressing the icon. The appliance buzzer

sounds three times (ascending) and all buttons light up in sequence.

2. Select the desired cooking mode by turning the SELECTOR knob. The

display shows:

- the temperature associated with the mode, if programming manually;

- “Auto” and the duration alternately, if programming is automatic.

3. Press the icon to begin cooking.

4. The oven will begin its preheating phase, the preheating indicators will light

up as the temperature rises.

5. When the preheating process has nished, a buzzer sounds and all the

preheating indicator lights show that this stage has been completed: the food

can then be placed in the oven.

6. During cooking it is always possible to:

- modify the temperature by turning the THERMOSTAT knob (manual

modes only);

- set the duration of a cooking mode (see Cooking Modes);

- press the icon to stop cooking. In this case the appliance stores the

temperature modied previously in its memory (manual modes only);

- switch off the oven by pressing the icon for 3 seconds.

7. If a blackout occurs while the oven is already in operation, an automatic

system within the appliance will reactivate the cooking mode from the point at

which it was interrupted, provided that the temperature has not dropped below

a certain level. Programmed cooking modes which have not yet started will

not be restored and must be reprogrammed (for example: a cooking mode

has been programmed to start at 20:30. At 19:30 a blackout occurs. When the

power supply is restored, the mode will have to be reprogrammed).

! The oven will begin its preheating phase after 2 seconds from selecting

the desired cycle.

! There is no preheating stage for the GRILL mode.

! Never put objects directly on the bottom of the oven; this will prevent the

enamel coating from being damaged.

! Always place cookware on the rack(s) provided.

! The oven will begin its preheating phase after 2 seconds from selecting

the desired cycle.
