Electrical connection

• The installation of this appliance and the connection to the electrical network should be

entrusted only to an electrician perfectly to the fact of the normative regulations and which

respects them scrupulously.

• Protection against the parts under tension must be ensured after the building-in.

• The data of connection necessary are on the stickers place on the hob casing near the

connection box.

• The connection to the main must be made using an earthed plug or via an omnipolar

circuit breaking device with a contact opening of at least 3 mm.

• The electrical circuit must be separated from the network by adapted devices, for example:

circuit breakers, fuses or contactors.

• If the appliance is not fitted with an accessible plug, disconnecting means must be

incorporated in the fixed installation, in accordance with the installation regulations.

• The inlet hose must be positioned so that it does not touch any of the hot parts of the hob

or even.

Caution!

This appliance has only to be connected to a network 230 V~ 50/60 Hz.

Connect always the earth wire.

Respect the connection diagram.

The connection box is located underneath at the back of the hob casing. To open the cover use a

medium screwdriver. Place it in the slits and open the cover.

* calculated with the simultaneous factor following the standard EN 60 335-2-6

Connection of the hob

Setting up the configurations:

For the various kinds of connection, use the brass bridges which are in the box next the terminal

Monophase 230V~1P+N

Put a bridge between terminal L1 and L2 and between terminal N1 and N2.

Attach the earth to the terminate “earth”, the neutral N to one of the terminals N1 or N2, the

Phase L to one of the terminals L1 or L2.

Biphase 400V~2P+N

Put a bridge between terminal N1 and N2.

Attach the earth to the terminate “earth”, the neutral N to terminal N1 or N2, the Phase L1 to the

terminals L1 and the Phase L2 to the terminal L2.

Mains Connection Cable diameter Cable Protection calibre

230V~ 50/60Hz 1 Phase + N 3 x 2,5 mm² H 05 V2V2 - F

25 A *

400V~ 50/60Hz 2 Phases + N

4 x 1.5 mm² H 05 V2V2 - F

16 A *

We cannot be held responsible for any incident resulting from incorrect connection or

which could arise from the use of an appliance which has not been earthed or has been

equipped with a faulty earth connection.
