Avago Technologies
- 24 -
12Gb/s MegaRAID SAS RAID Controllers User Guide
February 2015
Chapter 3: MegaRAID SAS RAID Controller Characteristics
12GB/s MegaRAID SAS RAID Controller Family
The following table describes the jumpers and the connectors on the MegaRAID SAS 9341-8i RAID controller.
3.1.2 MegaRAID SAS 9361 RAID Controllers
The MegaRAID SAS 9361-4i low-profile SATA+SAS RAID controller controls four internal SAS/SATA ports through one
SFF-8643 internal mini-SAS HD-4i connector.
The MegaRAID SAS 9361-8i low-profile SATA+SAS RAID controller controls eight internal SAS/SATA ports through two
SFF-8643 internal mini-SAS HD-4i connectors.
Table 3 Jumpers and Connectors
Jumper/
Connector
Type Description
EC1 Standard edge card connector The interface between the RAID controller and the host system.
Along with the PCIe interface, this connector provides power to the board
and an I
2
C interface connected to the I
2
C bus for the Intelligent Platform
Management Interface (IPMI).
J1A x4 SAS Port 0 through Port 3 internal
connector
Two SFF-8643 mini-SAS HD-4i internal connectors
Connects the controller by cable to SAS drives or SATA drives.
J1B x4 SAS Port 4 through Port 7 internal
connector
Two SFF-8643 mini-SAS HD-4i internal connectors
Connects the controller by cable to SAS drives or SATA drives.
J2 CPLD header 10-pin header
Reserved for Avago use.
J3 Modular RAID Key header 2-pin connector
Reserved for Avago use.
J4 On-board Serial Universal
Asynchronous Receiver/Transmitter
(UART) connector
4-pin connector
Reserved for Avago use.
J5 RISCwatch header 16-pin header
Reserved for Avago use.
J6 Avago Test header 2-pin connector
Reserved for Avago use.
