Avago Technologies
- 38 -
12Gb/s MegaRAID SAS RAID Controllers User Guide
February 2015
Chapter 3: MegaRAID SAS RAID Controller Characteristics
Technical Specifications
The supply voltages are 12V ± 8 percent (from PCI edge connector only) and 3.3V ± 9 percent (from PCI edge
connector only). The following table lists the power supply for the RAID controllers for these three states at the
different voltages.
3.3.4.6 Operating and Nonoperating Conditions for MegaRAID SAS 9380-4i4e RAID Controllers
For the MegaRAID SAS 9380-4i4e RAID controller, the operating (thermal and atmospheric) conditions are as follows:
Relative humidity range is 20 percent to 80 percent noncondensing
Airflow must be at least 200 linear feet per minute (LFPM) to avoid operating the LSISAS3108 processor above the
maximum ambient temperature
Temperature range: 10 °C to +55 °C (with or without the CVFM04 module attached)
NOTE To maximize the lifespan of the CVPM module, keep the ambient
temperature as low as possible.
The parameters for the nonoperating (such as storage and transit) environment for these controllers are as follows:
Relative humidity range is 5 percent to 90 percent noncondensing.
Temperature range: –40 °C to +70 °C
3.3.4.7 Power Supply Requirements for the MegaRAID SAS 9380-8e RAID Controllers
All power is supplied to the MegaRAID SAS 9380-8e RAID controllers through the PCIe 3.3V rails and the 12V rail.
Onboard switching regulator circuitry operating from the 3.3V rails and the 12V rail provides the necessary voltages.
The following states determine the typical current consumption of the controller:
State 1: While sitting idle at the DOS prompt
State 2: During a drive stress test
State 3: Power on the controller with a deeply depleted CVPM module attached
The supply voltages are 12V ± 8 percent (from PCI edge connector only) and 3.3V ± 9 percent (from PCI edge
connector only). The following table lists the power supply for the RAID controllers for these two states at the
different voltages.
Table 13 Power Supply for MegaRAID SAS 9380-4i4e RAID Controllers
PCI Edge Connector State 1 State 2 State 3
3.3V supply 727 mA 1030 mA 1280 mA
+12V supply 1050 mA 1410 mA 1640 mA
3.3V auxiliary supply 10 mA 10 mA 10 mA
Total Power 15.212 W 20.574 W 24.153 W
Table 14 Power Supply for MegaRAID SAS 9380-8e RAID Controllers
PCI Edge Connector State 1 State 2 State 3
3.3V supply 800 mA 880 mA 800 mA
+12V supply 1000 mA 1220 mA 1520 mA
3.3V auxiliary supply 20 mA 20 mA 10 mA
Total Power 14.95 W 17.91 W 21.266 W
