Robomow MS1800 [12/58] Main sub zone with a narrow pass

11

3.1.2 “Main Zone + Sub-Zone(s)“ Type Lawn

This type of lawn consists of more than

one zone, where zones are connected by

a narrow pass.

In this type of lawn, Robomow will be able

to drive from one zone to the other in order

o Is there a Narrow Pass of at least 1m (3.3 ft.) for Robomow to drive between these zones?

o Is this Narrow Pass rm, in one level and smooth (not stony, sandy or elevated)?

For example: grass area, sidewalk, rm path, solid ground.

Such additional areas are called Sub-Zones.

If your lawn contains a Sub-Zone as dened in this section, refer to Section 6.4.2 (Add Sub-Zone – number

p022 in the table).

Dening Sub-Zone(s) will enable Robomow to drive through the Narrow Pass in order to get to a Sub-Zone and

to mow both the Main Zone and its Sub-Zone(s) one zone at a time.

If your lawn does not match this description, skip to the next Section 3.1.3 of this chapter: “Separate Zones”.

3.1.3 “Separated Zones” Type Lawn

Or

o Are parts of your lawn separated by

a gravel path or similar material that

may damage the mower blade?

Or

o Are the zones of your lawns joined

by a pass that is too narrow for

Robomow to drive through: less

than 1m (3.3 ft.) in width?

Or

 A lawn may consist of up to 2 Separated Zones

 The mower must be carried or driven to this area manually.

 Any of the 3 types can be a combination of more than one type of lawn.

Sub-Zone
