17
Specifications
Continued from previous page
USB
y ASMedia
®
ASM1142 Chipset
2x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) port on the
back panel
y Intel
®
Z170 Chipset
7x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the
back panel, 1 internal port, 2 ports available through the
internal USB connector)
7x USB 2.0 (High-speed USB) ports (3 ports on the
back panel, 4 ports available through the internal USB
connectors)
Audio
y Realtek
®
ALC1150 Codec
y 7.1-Channel High Definition Audio
y Supports S/PDIF output
LAN 1x Intel I219-V Gigabit LAN controller
Back Panel
Connectors
y 1x PS/2 keyboard/ mouse combo port
y 3x USB 2.0 ports
1x HOTKEY port
1x BIOS FLASHBACK+ port
y 1x Clear CMOS button
y 2x HDMI
™
ports
y 1x DisplayPort
y 2x USB 3.1 Gen2 ports
y 4x USB 3.1 Gen1 ports
y 1x LAN (RJ45) port
y 1x Optical S/PDIF OUT connector
y 5x OFC audio jacks
Continued on next page
