Microlab iH11, black [3/4] Introduction

Microlab iH11, black [3/4] Introduction
5
Introduction
Technical Information
19. Servicing - Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
20. Please remove the power plug form the main power source or wall power source when not in use. When plugged in to a
power source, the system is in standby mode, so the power is not entirely cut off.
21. Replacement parts - When replacement parts are required, ensure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock or other hazards.
22. Mains fuses - For continued protection against fire hazard, use fuses only of the correct type and rating. The correct fuse
specification for each voltage range is marked on the product.
23. Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the speaker
may be damaged when a peak level section is suddenly played.
24. The only means of completely disconnecting the product from the power supply is by removing the power cord from the
wall outlet or the product. The wall outlet or the power cord entry to the product must remain freely accessible at all times
while the product is in use.
25. Try to install the product near a wall socket or exetension cord and shall be easily accessible.
26. The highest environmental temperature suitable for this product is 40 C.
o
Specifications
2
Features
* Powerful 2.0 stereo speakers with iDock system
* High quality wood cabinets with bass reflex system for depth and low Bass
* Carefully designed speaker drivers to match all digital media Playbacks
* Full range and powerful acoustic with perfect linear response
* Optimized iDock system for charging and iPod playback
Made for iPod:
iPod (20GB, 30GB, 40GB, 60GB only),
iPod (photo) 40GB, 60GB only,
iPod (color) 30GB, 60GB only,
iPod (video) 30GB, 60GB, 80GB only,
iPod mini (4GB, 6GB only),
iPod nano (1GB, 2GB, 4GB, 8GB only)
Amplifier
Speakers
Power
Interfaces
Dimensions
Output power: 40 Watt RMS
Power distribution: 20 Watt x 2
Harmonic distortion: < 0.3% IW 1kHz
Frequency response: 60Hz - 40kHz
Signal/Noise ratio: > 80dB
Separation: > 50dB
Input sensitivity: 360mV
Nominal impedance: 6 ohm
Tweeter driver type: 1"
Tweeter rated power: 10 Watt
Bass driver type: 4"
Bass rated power: 30 Watt
Speaker power supply: AC 120V ~ 60Hz, 540mA
iDock power supply: AC 100V - 240V, 60Hz
OUTPUT: 2 sets of terminal binding posts
INPUT: 2RCA, 3.5mm stereo jack
Product dimension: 145 x 254 x 230mm(W x H x D)
Product net weight: 7.2kg
Giftbox dimension: 364 x 275 mm
Giftbox gross weight: 7.8kg
327x (W x H x D)
Package contents
iH11 Speaker 2pcs
iDock 1pc
Power a pc
RCA-RCA video signal cable 1pc
3.5mm - 3.5mm audio signal cable 1pc
2 RCA - 2 RCA audio signal cable 1pc
User manual
daptor 1
Infrared remote control 1pc
Type AAA batteries 2pcs
1pc
The perfect difinitive combo, Microlab own iDock and H11 high fidelity speakers we offer you
great quality solution with perfect full ranges dynamic audio production and multiple media
connections. Perfect clarity from mid to highs, and depth in bass.
The iH11 gives you great options for most of your digital media playbacks. Connect your
media players via RCA or even 3.5mm stereo jack. Support various playback players such as
CD/DVD, iPod, iPod docking/charging, and TV monitors, etc.
iPod is a trademark of Apple Inc., registered in the U.S. and other countries
"Made for iPod" means that an electronic accessory has been designed to connect specifically to iPod and has
been certifed by the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.
* iPod not included in package
