Panasonic tx-32cr410 [10/24] Using media player
![Panasonic tx-32cr410 [10/24] Using media player](/views2/1176802/page10/bga.png)
Using TV Guide | Watching External Inputs | Using Media Player
10
Using TV Guide
The TV Guide - Electronic Programme Guide (EPG),
shows a list of broadcasts for several days (depending
on the broadcasters).
●
When this TV is turned on for the first time, or switched
off for more than a week, it may take some time before
the TV Guide is completely shown.
●
DVB-T and Analogue channels are displayed on the
same TV Guide screen. There will be no programme
listings for Analogue channels.
●
TV mode only.
Display the TV Guide.
GUIDE
Example:
06/12/2015
8:00 9:00
Schleswig-Holst...
Schleswig-Holst...
Schleswig-Holst...
Schleswig-Holst...
Haral... Rucksack artour Leben für 4... MDR...
Haral... Rucksack artour Leben für 4... MDR...
Haral... Rucksack artour Leben für 4... MDR...
buten un binnen... Hallo Niedersac... Das Beste aus E...
Hallo Niedersac... Das Beste aus E...
Hallo Niedersac... Das Beste aus E...
Hallo Niedersac... Das Beste aus E...
buten un binnen...
buten un binnen...
buten un binnen...
8:00 - 8:30 Schleswig-Holstein Magazin
NDR FS NDS
117 NDR FS NDS
118 NDR FS HH
119 NDR FS SH
120 NDR FS MV
122 MDR Sachsen
123 MDR S-Anhalt
124 MDR Thüringen
A
A
A
A
A
A
A
TV Guide Tuesday, 6-December-2015 13:10:28
Time:
NEWS
Select
Programme
Information
Next day Type filter
Page up
Page down
EXIT
RETURN
3
5
2
4
1
1
Current date and time
2 TV Guide date
3 TV Guide time
4 Programme
5 Channel position and name
Follow the operation guide to operate the TV
Guide.
Note
●
It may be slow to response when pressing the UP/
DOWN cursor button for TV program guide. This is due
to program data downloading.
[Type filter]
Lets you view a channel list of the selected type filter.
(blue) (Press again to return to TV Guide.)
(Type list)
Type Subtype
MOVIE
Drama
NEWS Detective
When you highlight on [Type], the corresponding
[Subtype] will be shown. [Type] / [Subtype] are multi-
selectable.
OK
Select [Type]/[Subtype]
screen
OK
Add/Remove
Select [Type]/[Subtype]
item
Watching External
Inputs
1 Connect the external equipment.
(p. 6 - 7)
2 Display the [Input Selection] menu,
then select the input of the connected
equipment.
Example:
Input Selection
TV
HDMI 1
AV1
AV2
HDMI 2
Note
●
You can label or skip each input mode.
[Input Labels] (p. 15)
Skipped inputs will not be displayed when the AV
button is pressed.
●
If the external equipment has an aspect adjustment
function, set it to “16:9”.
Using Media Player
Media Player allows you to enjoy photo, music or video
recorded on a USB Flash Memory.
●
During the operation, audio signal is output from AV1,
DIGITAL AUDIO and HDMI2 (ARC function) terminals.
To use HDMI 2 with ARC function, connect an amplifier
that has ARC function and set to use theatre speakers
(p. 7).
●
The picture may not appear correctly on this TV
depending on the digital cameras used.
●
Display may take some time when there are many files
and folders in the USB Flash Memory.
●
Partly degraded files might be displayed at a reduced
resolution.
●
The folder and file names may be different depending
on the digital camera used.
Inserting / Removing the USB Flash
Memory
TV
●
Insert or remove
straight and
completely.
