Using Media Player | Using Common Interface | Using the Menu Functions
12
[Option Menu]
■ [Music Setup Menu]
– [Repeat]:
• [One]: Playback repeat on the selected one file.
• [Folder]: Playback repeat within the selected folder.
• [Off]: Playback repeat off.
Movie mode
My Movie_1
My Movie_2
My Movie_3
Media Player Movie Title view
USB
EXIT
Select
RETURN
Play Folder Contents Select
Info
Access
Option Menu
Drive Select
Operation guide
[Play Folder]
Playbacks all movies in the selected folder.
(red)
■ To playback the selected file only
Select the folder. Select the file.
OK
Access
Select
OK
Play
Select
[Option Menu]
■ [Video Setup Menu]
– [Multi Audio]: Selects the sound tracks (if available)
during video playback.
– [Subtitle]: Selects the subtitle (if available) during
video playback.
– [Aspect Change]: Selects the aspect mode during
video playback. [Auto] / [16:9] / [14:9] / [Just] / [4:3] /
[4:3 Full] / [Zoom1] / [Zoom2] / [Zoom3]
• You can also change the aspect by pressing the
ASPECT button repeatedly.
– [Repeat]: Playback repeat options. [Off] / [On]
Using Common
Interface
Turn the TV off with the Mains Power On / Off switch
whenever inserting or removing the CI module.
Insert the module in the correct
direction, then follow the on-screen
instructions.
Common Interface
TV
CI module
Normally encrypted channels will appear. If encrypted
channel does not appear
[Common Interface]
(p. 16)
●
If a smart card and a CI module come as a set, first
insert the CI module, then insert the smart card into the
CI module.
●
Features that appear on the screen are dependent on
the contents of the selected CI module.
●
There might be some CI modules in the market with
firmware versions that do not fully interoperable with
this TV. In this case, please contact your content
provider.
●
For more information, read the manual of the CI
module, or check with the content provider.
Using the Menu
Functions
1 Display the menu.
MENU
Example:
Menu Item Setting
Mode
Music
Bass
Sound Menu
Treble
Balance
Auto Gain Control
Surround
Volume Correction
Speaker Distance to Wall
SPDIF Selection
Off
PCM
Main Menu
Sound
Timer
Setup
Select
Page up
Change
RETURN
Page down
Operation guide
S
elec
t
Pa
g
e u
p
Change
R
ET
U
R
N
Pa
g
e dow
n
Main
Menu
P
ictur
e
Sound
Timer
Setu
p
Mode
Bass
Sound Menu
Treb
le
B
a
l
a
n
ce
Auto
Gai
n Co
ntro
l
S
urr
ound
Volu
me C
orre
ctio
n
S
peaker Distance to Wall
SPDI
F Se
lect
ion
Mus
i
c
Off
PCM
Headphone Volume
Over 30cm
Off
