Using the Menu Functions
16
■ [Radio Mode]
Sets the timer to turn off the screen automatically when
a radio channel is selected.
[Off] / [5 / 10 / 15 / 20 seconds]
– The sound is active even when the screen is off.
This function could reduce power consumption when
listening to a radio channel.
– Press any button except Standby, Volume Up / Down
and Sound Mute buttons to turn on the screen.
– Not available in Analogue TV mode.
[System Menu]
■ [Shipping Condition]
Resets all settings, including tuning data, to the original
condition.
– Access this function and follow the on-screen
instructions to complete the procedures.
– Initial Setup (p. 7) will automatically start after
[Shipping Condition] completes.
■ [Common Interface]
Sets to watch encrypted channels, etc.
(p. 12)
■ [System Update] (p. 18)
■ [Software Licence]
Displays the software licence information.
■ [System Information]
Displays the software version.
[Power Save]
Reduces brightness of picture to economise on power
consumption. [Off] / [On]
Using the [Tuning Menu]
Use the [Tuning Menu] to retune the TV automatically or
manually, add new channels, check signal conditions,
create your favourite channel lists, skip unwanted
channels, etc.
[TV Selection]
Selects the signal mode to tune.
• [Antenna] : DVB-T and Analogue scan.
• [Cable]: DVB-C and Analogue scan.
[Auto Tuning]
Retunes the channels received in your area
automatically.
●
Automatically searches and adds available channels to
the memory.
●
Before performing this function, select the signal mode
to tune in [TV Selection].
●
After the scan is complete, all previously saved
channels will be erased.
Automatic Channel Search
Status: Scanning...
Analogue : 0
Digital : 1
EXIT
RETURN
Scan
5%
●
When the operation is completed, the channel at the
lowest position will be displayed.
●
If tuning has not been done completely, perform
[Analogue Manual Tuning].
[Scan]
Adds new channels automatically to the channel list.
Example: Antenna
Scan
Status: Scanning...
Analogue : 0
Digital : 1
Scan
5%
[Analogue Manual Tuning]
Sets analogue channel manually.
Example: Antenna
Analogue Manual Tuning
Searching Channels
Scan up
Scan down
Start Frequency (MHz) 48.00
1 Enter the frequency to start scanning.
2 Select the scanning method.
OK
Select
• [Scan up]: Scans ascendingly from the entered
frequency to higher frequencies.
• [Scan down]: Scans descendingly from the entered
frequency to lower frequencies.
[DVB-C Signal Condition] / [DVB-T Signal
Condition]
Shows the DVB-C / DVB-T signal condition.
Example:
Signal Level
Signal Condition
100
100
These bars show the maximum signal value of the
selected channel.
