Princess 233022 [10/48] U k wiring instructions
![Princess 233022 [10/48] U k wiring instructions](/views2/1178018/page10/bga.png)
10
EN
This appliance is intended to be used in •
domestic and similar applications such as
staff kitchen areas in shops, offices and
other working environments; farm houses;
by clients in hotels, motels and other
residential type environments; bed-and-
breakfast type environments.
Electrical safety
Before use, always check that the mains •
voltage is the same as the voltage on the
rating plate of the appliance.
The appliance is not intended to be •
operated by means of an external timer or
separate remote-control system.
Connect the appliance to an earthed wall •
socket. If necessary, use an earthed
extension cable of a suitable diameter
(at least 3 x 1 mm
2
).
For additional protection, install a residual •
current device (RCD) with a rated residual
operating current that does not exceed
30 mA.
Make sure that water cannot enter the •
contact plugs of the mains cable and the
extension cable.
Always fully unwind the mains cable and •
the extension cable.
Make sure that the mains cable does not •
hang over the edge of a worktop and
cannot be caught accidentally or tripped
over.
Keep the mains cable away from heat, oil •
and sharp edges.
Do not use the appliance if the mains cable •
or the mains plug is damaged or defective.
If the mains cable or the mains plug is
damaged or defective, it must be replaced
by the manufacturer or an authorised
repair agent.
Do not pull the mains cable to disconnect •
the mains plug from the mains.
Disconnect the mains plug from the mains •
when the appliance is not in use, before
assembly or disassembly and before cleaning
and maintenance.
Safety instructions for water boilers
Do not use the appliance outdoors.•
Place the appliance on a stable and flat •
surface.
Place the appliance on a heat-resistant and •
splash-proof surface.
Make sure that there is sufficient space •
around the appliance to allow heat to
escape and provide sufficient ventilation.
Do not cover the appliance.•
Make sure that the appliance does not •
come into contact with flammable material.
Keep the appliance away from heat sources.•
Only use the appliance with the supplied •
base.
Only switch on the appliance when the •
appliance is filled with water.
Do not move the appliance while it is •
switched on.
Be careful with hot water and steam to •
avoid burns.
Store the appliance in a dry place when •
not in use. Make sure that children do not
have access to stored appliances.
U.K. Wiring instructions
The wires in the mains lead are coloured in
accordance with the following code:
BLUE NEUTRAL
BROWN LIVE
GREEN/YELLOW EARTH
As the colours of the wire in the mains lead of
this appliance may not correspond with the
colour markings identifying the terminals on
your plug, proceed as follows:
The wire which is coloured BLUE must be
connected to the terminal which is marked
with the letter N or coloured black.
The wire which is coloured BROWN must be
connected to the terminal which is marked
with the letter L or coloured red.
The wire which is coloured GREEN/YELLOW
must be connected to the terminal which is
marked with the letter E or
and is coloured
GREEN or GREEN/YELLOW.
