TD-W8961ND
Wireless N ADSL2+ Modem Router User Guide
IP-адрес, статический IP-адрес, PPPoA/PPPoE и соединение типа «мост». Выберите
тип подключения, который вы собираетесь использовать.
1) Dynamic IP Address Динамический IP-адрес
Select this option if your ISP provides you an IP address automatically. This option is typically
used for Cable services. Please enter the Dynamic IP information accordingly. Выберите эту
опцию, если ваш Интернет-провайдер предоставляет вам IP-адрес автоматически. Эта
опция обычно используется абонентами кабельных сетей. Укажите соответствующую
информацию о динамическом IP-адресе.
Figure 4-23 Рис. 4-7
Encapsulation: Select the encapsulation mode for the Dynamic IP Address, you can leave
it default.
NAT: Select this option to Enable/Disable the NAT (Network Address Translation) function
for this VC. The NAT function can be activated or deactivated per PVC basis.
Default Route: If enable this function, the current PVC will be considered as the default
gateway to internet from this device.
TCP MTU Option: Enter the TCP MTU as your desire.
Dynamic Route: Select this option to specify the RIP (Routing Information protocol) version
for WAN interface, including RIP1, RIP2-B and RIP2-M. RIP2-B and RIP2-M are both sent in
RIP2 format, the difference is that RIP2-M using Multicast, while RIP2-B using Broadcast
format.
Direction: Select this option to specify the RIP direction. None is for disabling the RIP
function. Both means the ADSL Router will periodically send routing information and
accept routing information, and then incorporate them into routing table. IN only means
the ADLS router will only accept but will not send RIP packet. OUT only means the
29
