Ricoh wg-5 [88/244] Changing the autofocus area
![Ricoh wg-5 [88/244] Changing the autofocus area](/views2/1178839/page88/bg58.png)
86
3
Taking Pictures
5
Press the 4 button.
The focus is locked and the camera returns to capture mode.
After the focus is locked, you can press the four-way controller (5) again to
display the \ indicator and readjust the focus.
You can change the autofocus area (Focusing Area).
1
Use the four-way controller (23) to select [AF Setting] in the
[A Rec. Mode] menu.
2
Press the four-way controller (5).
The [AF Setting] screen appears.
3
Use the four-way controller (23) to select [Focusing Area].
4
Press the four-way controller (5).
A pull-down menu appears.
5
Use the four-way controller (23) to change the autofocus
area.
6
Press the 4 button.
The setting is saved.
The shooting mode and drive mode cannot be changed while the \
indicator is displayed.
To switch from \ to another focus mode, press the four-way controller (5)
while the \ indicator is displayed.
Changing the Autofocus Area
J Multiple Uses the normal autofocus area.
K Spot Makes the focusing area smaller.
W Automatic Tracking Tracks a moving subject and keeps it in focus.
The available modes differ depending on the selected shooting mode. Refer
to “Functions Available for Each Shooting Mode” (p.210) for details.
