38
IPSEC Tunnel Mode
IPsec tunnels can be added, modified, or deleted
from the DFL-100 by clicking the appropriate
click-box and then the Apply button.
Remote Tunnel ID
An alphanumeric string that identifies the remote
tunnel. A sting of up to 63 characters can be
entered.
Remote Gateway IP
Enter the IP address of the remote gateway on
the other end of the IPsec connection.
Remote IP Network
Enter the IP address of the remote network. This
is a reserved IP address from the range of IP
addresses assigned to the remote network. For
example, if the remote network uses an IP
address range of 192.168.0.0 to 192.168.0.255
and a subnet mask of 255.255.255.0 would use
the first IP address of the range as its network
address − 192.168.0.0.
Remote IP Netmask
Enter the subnet mask used by the remote
network here.
Pre-Shared Key
This is an encryption key used to encrypt packets
sent between the two ends of the IPsec tunnel.
IKE Encryption
You can select the encryption used to provide
the IPsec function using the drop-down menu.
The choices are DES, and 3DES. The exact
same encryption algorithm must be used on both
ends of the IPsec connection.
IKE Hash
You can select the algorithm the IPsec
connection will use to verify that packets have
not been altered in transit. The choices are
MD5, and SHA. The exact same IKE Hash
algorithm must be used on both ends of the IPsec
connection.
IKE Life Duration
This is used to specify the length of time that the
IKE key can be in use before being updated with
a new key. The default is 86400 seconds.
SA Life Duration
This is used to specify the length of time that the
IKE Security Association (SA) can be in effect
before being updated. The default is 28800
seconds.
