Chapter 1: Introduction
1-7
ACPI Features
• Slow blinking LED for suspend state indicator
• Main switch override mechanism
• ACPI Power Management
• Keyboard Wakeup from Soft-off
Onboard I/O
• Intel ICH10R supports six SATA2 ports (with RAID0, RAID1, RAID10, RAID5
supported in the Windows OS and RAID0, RAID1, RAID10 in the Linux plat-
forms) (Note 1)
• LSI 1068E supports eight SAS ports support RAID0, RAID1, RAID10, and op-
tional RAID5 w/I-Button 68 (For X8DTL-3/-3F) (Note 2)
• Dual 82574L Gigabit Ethernet controllers support Gigabit LAN1/2 ports
• A PHY chip supports the Dedicated IPMI LAN (X8DTL-iF/3F only) (Note 3)
• One VGA Port supported by the Winbond G200EW
• Two COM ports(1 header, 1 port)
• PS/2 mouse and PS/2 keyboard ports
• Up to seven USB 2.0 (Universal Serial Bus) (2 Backpanel USB Ports, 1 Front
USB Header, and 2 Type A Headers)
• Super I/O: Winbond W83627DHG-P
• IPMI 1.5/2.0 with full KVM support (X8DTL-3F/iF only) (Note 3)
Other
• Wake-on-LAN (WOL) and Wake-on-Ring (WOR)
• Console redirection
• Onboard Fan Speed Control by Thermal Management via BIOS
CD/Diskette Utilities
• BIOS ash upgrade utility and device drivers
Dimensions
• Ext. ATX 12.00" (L) x 10.00" (W) (304.80 mm x 254.20 mm)
Note 1: For more information on SATA HostRAID conguration, please
refer to the Intel SATA HostRAID User's Guide posted on our website @
http://www.supermicro.com/support/manuals/.
Note 2: For more information on LSI SAS RAID conguration, please refer
to the LSI MegaRAID User's Guide posted on our website @ http://www.
supermicro.com/support/manuals/.
Note 3: For more information on IPMI conguration, please refer to the
Embedded IPMI User's Guide posted on our website @ http://www.super-
micro.com/support/manuals/.
