F-4
SC743 Chassis Manual
F-6 Front Connector and Jumper Pin Denitions
1. Overheat Temperature Jumper
OH TEMP: JP25
Open: 45º C
1-2: 50º C (Default)
2-3: 55º C
Backplane
Main Power
4-Pin Connector
Pin# Denition
1
+12V
2 and 3 Ground
4 +5V
2. Backplane Main Power Connectors
The 4-pin connectors designated JP10 and
JP13 provide power to the backplane. See the
table on the right for pin denitions.
SATA Activity LED Header
Pin Denitions
Pin # Denition Pin # Denition
1 ACT IN#0 6 ACT IN#4
2 ACT IN#1 7 ACT IN#5
3 ACT IN#2 8 ACT IN#6
4 ACT IN#3 9 ACT IN#7
5 Ground 10 Empty
3. Activity LED Connector
The activity LED connector, designated JP26,
is used to indicate the activity status of each
SATA drive. The activity LED connector is lo-
cated on the front panel. For the activity LED
header to work properly, connect using a 10-pin
LED cable.
4. - 11. SATA Ports
The SATA ports are used to connect the SATA
drive cables. The eight SATA ports are desig-
nated #0 - #7.
12. Buzzer Reset
The buzzer reset jumper allows the buzzer to
be reset when an alarm has occured.
