5-22
SUPERSERVER 6027R-3RF4+ User's Manual
IPMB I
2
C Header
An SMB header for the IPMI (Intel-
ligent Platform Management Inter-
face) slot is designated J5. Connect
the appropriate cable here to utilize
this management feature on your
system.
IPMB Connector
Pin Defi nitions
Pin# Defi nition
1 Data
2 Ground
3 Clock
4 No Connection
RAIDKey Header (Optional)
A RAIDKey header provides RAID 5
support to enhance the performance
of Intel HostRAID and LSI Mega-
RAID.
Note: RAIDKey: SMCI Part# AOC-
IMRRAKey-2008-LSI
DOM Power Connector
A power connector for SATA DOM
(Disk_On_Module) devices is located
at JSD1. Connect an appropriate
cable here to provide power support
for your DOM devices.
DOM PWR
Pin Defi nitions
Pin# Defi nition
1 +5V
2 Ground
3 Ground
RAIDKey
Pin Defi nitions
Pin# Defi nition
1 Ground
2 Signal
3 Ground
IPMB
A System Management Bus header
for IPMI 2.0 is located at IPMB. Con-
nect the appropriate cable here to
use the IPMB I
2
C connection on your
system.
IPMB Header
Pin Defi nitions
Pin# Defi nition
1 Data
2 Ground
3 Clock
4 No Connection
Power Supply SMBus I
2
C Header
The power System Management Bus
header at JPI
2
C1 is used to monitor
the status of the power supply, fan and
system temperature. See the table on
the right for pin defi nitions.
PWR SMBus Header
Pin Defi nitions
Pin# Defi nition
1 Clock
2 Data
3 PWR Fail
4 Ground
5 +3.3V
