Chapter 5: Advanced Serverboard Setup
5-29
5-12 SATA and SAS Ports
SAS Port
Pin Defi nitions
Pin# Defi nition Pin Defi nition
1 Ground 2 TXP
3 TXN 4 Ground
5 RXN 6 RXP
7 Ground
SATA Port
Pin Defi nitions
Pin# Defi nition Pin Defi nition
1 Ground 2 TXP
3 TXN 4 Ground
5 RXN 6 RXP
7 Ground
Note: For more information on SATA HostRAID confi guration, please refer to the
Intel SATA HostRAID User's Guide posted on our Website @ http://www.supermi-
cro.com..
Serial ATA Ports
There are six Serial ATA Ports (I-
SATA0~I-SATA 5) located on the
serverboard, including four SATA2
ports and two SATA3 ports. These
ports provide serial-link signal con-
nections, which are faster than Paral-
lel ATA. See the table on the right for
pin defi nitions.
SAS Ports
Eight Serial Attached SCSI ports
(SAS 0~3, 4~7) provide serial link
connections. These ports are sup-
ported by the Intel PCH chip. See the
table on the right for pin defi nitions.
