1. CONFIGURATION OVER WEB BROWSER

1.13 Mobile WAN conﬁguration

This item is not available for industrial router XR5i v2.

The form for conﬁguration of a connection to the mobile network can be invoked by select-

ing the Mobile WAN item in the main menu of the router web interface.

1.13.1 Connection to mobile network

If the Create connection to mobile network item is selected, the router automatically tries

to establish connection after switching-on.

Item Description

APN Network identiﬁer (Access Point Name)

Username User name to log into the GSM network

Password Password to log into the GSM network

Authentication Authentication protocol in GSM network:

• PAP or CHAP – authentication method is chosen by router

• PAP – it is used PAP authentication method

• CHAP – it is used CHAP authentication method

IP Address IP address of SIM card. The user sets the IP address, only in the case

IP address was assigned of the operator.

Phone Number Telephone number to dial GPRS or CSD connection. Router as a de-

fault telephone number used *99***1 #.

Operator This item can be deﬁned PLNM preferred carrier code

Network type

• Automatic selection – router automatically selects transmission

method according to the availability of transmission technology

• Furthermore, according to the type of router – it’s also possible to

select a speciﬁc method of data transmission (GPRS, UMTS, . . . )

PIN PIN parameter should be set only if it requires a SIM card router. SIM

card is blocked in case of several bad attempts to enter the PIN.

MRU Maximum Receiving Unit – It’s an identiﬁer of maximum size of packet,

which is possible to receive in a given environment. Default value is

1500 B. Other settings may cause incorrect transmission of data.

MTU Maximum Transmission Unit – It’s an identiﬁer of max. size of packet,

which is possible to transfer in a given environment. Default value is

1500 B. Other settings may cause incorrect transmission of data.

Table 19: Mobile WAN connection conﬁguration
