CONEL LR77 v2 [15/106] Configuration over web browser

1. CONFIGURATION OVER WEB BROWSER

1.4 WiFi

This item is available only if the router is equipped with a WiFi module.

After selecting the WiFi item in the main menu of the web interface, information about WiFi

access point (AP) and associated stations is displayed.

Item Description

hostapd state dump Time to which statistical data relates

num_sta Number of connected stations

num_sta_non_erp Number of connected stations using 802.11b in 802.11g

BSS connection

num_sta_no_short_slot_time Number of stations not supporting the Short Slot Time

num_sta_no_short_preamble Number of stations not supporting the Short Preamble

Table 8: State information about access point

For each connected client are displayed more detailed information. Most of them has an

internal character, so let us mention only the following:

Item Description

STA MAC address of connected device (station)

AID Identiﬁer of connected device (1 – 2007). If 0 is displayed, the station is

not currently connected.

Table 9: State information about connected clients

Figure 3: WiFi Status
