CONEL LR77 v2 [22/106] System log

1. CONFIGURATION OVER WEB BROWSER

In detecting the status of updates DynDNS record are possible following message:

• DynDNS client is disabled.

• Invalid username or password.

• Speciﬁed hostname doesn’t exist.

• Invalid hostname format.

• Hostname exists, but not under speciﬁed username.

• No update performed yet.

• DynDNS record is already up to date.

• DynDNS record successfully update.

• DNS error encountered.

• DynDNS server failure.

For correct function DynDNS, SIM card of router must have assigned public IP address.

1.10 System Log

In case of any problems with connection to GPRS it is possible to view the system log by

pressing the System Log menu item. In the window, are displayed detailed reports from indi-

vidual applications running in the router. Use the Save Log button to save the system log to a

connected computer. The second button – Save Report – is used for creating detailed report

(generates all support needed information in one ﬁle).

The Syslog default size is 1000 lines. After reaching 1000 lines create a new ﬁle for storing

system log. After completion of the 1000 lines in the second ﬁle, the ﬁrst ﬁle is deleted and

creates a new one.

Program syslogd can be started with two options that modiﬁes its behavior. Option "-s"

followed by decimal number set maximal number of lines in one log ﬁle. Option "-r" followed

by hostname or IP address enable logging to remote syslog daemon. In the Linux must be

enabled remote logging on the target computer. Typically running syslogd with the parameter

“-r”. On Windows must be installed the syslog server (for example Syslog Watcher). For

starting syslogd with these options you could modify script "/etc/init.d/syslog" or add lines

"killall syslogd" and "syslogd <options> &" into Star tup Script.
