1. CONFIGURATION OVER WEB BROWSER

After green LED starts to blink it is possible to restore initial settings of the router by press-

ing button RST on front panel. If press button RST, conﬁguration is restored to default and it

is reboot (green LED will be on).

1.1 Secured access to web conﬁguration

To the web conﬁguration can be accessed via a secure HTTPS protocol. In the event

of a default router IP address is a secure router conﬁguration accessed by entering address

https://192.168.1.1 in the web browser. The ﬁrst approach is the need to install a security cer-

tiﬁcate. If your browser reports a disagreement in the domain, this message can be prevented

use the following procedure.

Since the domain name in the certiﬁcate is given the MAC address of the router (such

separators are used dashes instead of colons), it is necessary to access the router under this

domain name. For access to the router via a domain name, it is adding a DNS record in the

DNS table, the operating system.

• Editing /etc/hosts (Linux/Unix)

• Editing C:\WINDOWS\system32\drivers\etc\hosts (Windows XP)

• Conﬁguring your own DNS server

In addition to conﬁguring the router with MAC address 00:11:22:33:44:55 is accessed to

secure conﬁguration by typing address https://00-11-22-33-44-55 in the web browser. The ﬁrst

approach is the need to install a security certiﬁcate.

When using self signing certiﬁcate must upload your ﬁles and http_cert http_key directory

/etc/certs in the router.

1.2 General

A summary of basic information about the router and its activities can be invoked by se-

lecting the General item. This page is also displayed when you login to the web interface.

Information is divided into a several of separate blocks according to the type of router activ-

ity or the properties area – Mobile Connection, Primar y LAN, Peripherals Ports and System

Information. If your router is equipped with WIFI expansion port, there is also WIFI section.

1.2.1 Mobile Connection

Item Description

SIM Card Identiﬁcation of the SIM card (Primary or Secondary)

Interface Deﬁnes the interface

Flags Displays network interface ﬂags

IP Address IP address of the interface
