Syma x11c [3/12] About contents
![Syma x11c [3/12] About contents](/views2/1190622/page3/bg3.png)
-2-
ABOUT CONTENTS
Product included
following contents:
Quadcopter
2.4G Remote controller
USB charging wire
Instruction manual
Reader
Blade(4 pieces)
Introduction of transmitter
Remote control Installing
the battery
Battery Cover
READY TO FLY YOUR QUAD COPTER
Step 1: First of all, press
the ON/OFF power switch.
Step 2: Insert the power line into
the quad copter and place it on
the level ground.
Video
Forward and
backward
trimmer
