Syma x11c [6/12] Illustration on how to control the quad copter mode 2
![Syma x11c [6/12] Illustration on how to control the quad copter mode 2](/views2/1190622/page6/bg6.png)
-5-
Push the throttle up or down, the quadcopter
flies upward or downward.
Push the direction lever up or down,the
quadcopter flies forward or backward.
Pull the direction lever left or right,the
quadcopter flies to left side or right side.
Pull the throttle left or right, the
quadcopter turns to left or right.
Operating direction
Fine-tuning operation
ILLUSTRATION ON HOW TO CONTROL
THE QUAD COPTER (MODE 2)
